PIPE SPAN CALCULATIONS

With this method, you may obtain :

· Recommended span between supports.

You may also find:
- Maximum SPAN and deflection to control allowable stress
- Stress and deflection according to SPAN Length (suggested by user)
- Lateral Force
- Vertical Force

Furthermore you can:
· Compare the span between supports of your convenience.

EXIT DATASHEET IS AS FOLLOWS :

To introduce the variables, you must fill in a format as follows:

INPUT FOR CALCULATION METHOD
PIPE SPAN CALCULATIONS

By :
Company :
Date :	01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC
Client :
Reference :	Case :
Pipeline Properties and Features :
Outside Diameter (OD) :	in ft mm
Wall Thickness (T) :	in ft mm
Modulus of Elasticy (E) :	psi
Allowable Stress :	psi
SPAN Length (By user) (L) :	in ft mm
Contacting Surface Between pipe and pipe support:	Steel on Steel (Dry) Steel on Steel (Lubricated) Steel on Lubrite Steel on Concrete (Dry) Steel on Concrete (Lubricated) Metal on Wood Metal on Asbestos

If you are sure press submit, if not refresh
